Good quality Shielded RJ45 Connector - HCJT4-812SK-L11 8P/8C Shielded Ganged 1×4 Quad Port Tab-Up RJ45 Ethernet Connectors – Zhusun Detail:

HCJT4-812SK-L11 8P/8C Shielded Ganged 1×4 Quad Port Tab-Up RJ45 Ethernet Connectors

QQ截图20210419125610

Categories  Connectors, Interconnects
 Modular Connectors - Jacks
Application-LAN  ETHERNET(NoN POE)
Connector Type  RJ45
Number of Positions/Contacts  8p8c
Number of Ports  1×4
Applications Speed  RJ45 Without Magnetics
Mounting Type  Through Hole
Orientation  90° Angle (Right)
Termination  Solder
Height Above Board  13.40 mm
LED Color  With LED
Shielding  Shielded, EMI Finger
Features  Board Guide
Tab Direction  UP
Contact Material  Phosphor Bronze
Packaging  Tray
Operating Temperature  -40°C ~ 85°C
Contact Material Plating Thickness  Gold 6.00µin/15.00µin/30.00µin/50.00µin
Shield Material  Brass
Housing Material  Thermoplastic
RoHS Compliant  YES-RoHS-5 WIth Lead in Solder Exemption



RJ is a kind of information socket (ie communication terminal) connector in the wiring system. The connector is composed of a plug (connector, crystal head) and a socket (module). The plug has 8 grooves and 8 contacts. RJ is the abbreviation of Registered Jack, which means “registered socket”. In FCC (Federal Communications Commission Standards and Regulations), RJ is an interface describing public telecommunications networks, and RJ for computer networks is a common name for standard 8-bit modular interfaces.






Product detail pictures:

Good quality Shielded RJ45 Connector - HCJT4-812SK-L11 8P/8C Shielded Ganged 1×4 Quad Port Tab-Up RJ45 Ethernet Connectors – Zhusun detail pictures
