New Arrival China 12 Pin LAN Transformers - H1294NL 100/1000Base-T Single Port Lan Transformer for Modules – Zhusun Detail:
H1294NL 100/1000Base-T Single Port Lan Transformer for Modules
| Categories | Transformers |
| Network Transforme | |
| Transformer Type | ETHERNET(NoN POE) |
| PIN Contacts | 24 |
| Number of Ports | Single Port |
| Mounting Type | Surface Mount |
| Turns Ratio - Primary:Secondary | 1CT:1CT |
| Packaging | SMD |
| Operating Temperature | -40°C ~ 85°C |
| Comment | SAME AS NL VERSION |
| Construction | OPEN FRAME |
| RoHS Compliant | YES-RoHS-5 WIth Lead in Solder Exemption |
The basic structure of the connector:
3. The shell, also called the shell, is the outer cover of the connector. It provides mechanical protection for the built-in insulation board and pins, and provides the alignment of the plug and socket when mating, and then fixes the connector to the device. on.
The basic structure of the connector:
4. Accessories The accessories are divided into structural accessories and device accessories. Structural accessories such as clamp rings, positioning keys, positioning pins, guide pins, connecting rings, cable clamps, sealing rings, gaskets, etc. Device accessories such as screws, nuts, screws, spring rings, etc. Most of the accessories have standard parts and common parts.
Product detail pictures:
