China Pulse JT7-1119NL Compatible ZhuSun Jack 10G Base-T Led Single Port PoE++ RJ45 Modular Socket factory and manufacturers

Pulse JT7-1119NL Compatible ZhuSun Jack 10G Base-T Led Single Port PoE++ RJ45 Modular Socket

Number of Ports: 1X1

Speed: 10G

Application-Lan : PoE

Latch: UP

LED: With LED

Orientation : 90°Angle (Right)

Compatible Brand : BEL

Mounting Type: Through Hole

Shielding: Shielded, EMI Finger

Temperature: ﹣40 TO ﹢85

Part Number:2250368-1

Pulse JT7-1119NL Compatible ZhuSun Jack 10G Base-T Led Single Port POE++ RJ45 Modular Socket

It can be used to support application, such as Smart Meters, Solar Inverter,

Categories	Connectors, Interconnects
Categories	Modular Connectors - Jacks With Magnetics
Application-LAN	ETHERNET(POE)
Connector Type	RJ45

Number of Ports	1×1
Applications Speed	10G Base-T, AutoMDIX PoE
Mounting Type	Through Hole
Orientation	90° Angle (Right)
Termination	Solder

LED Color	With LED
Shielding	Shielded, EMI Finger
Features	Board Guide
Tab Direction	UP
Contact Material	Phosphor Bronze
Packaging	Tray
Operating Temperature	-40°C ~ 85°C
Contact Material Plating Thickness	Gold 6.00µin/15.00µin/30.00µin/50.00µin
Shield Material	Brass
Housing Material	Thermoplastic
RoHS Compliant	YES-RoHS-5 WIth Lead in Solder Exemption
