XRJM-S-01-8-8-4 Tab-Up 1×1 Port 8P/8C Tab-Up Shielded RJ45 Ethernet Connectors

Number of Ports: 1X1

Speed: RJ45 Without Magnetics

Application-Lan : NoN PoE

Latch: UP

LED: With LED

Orientation : 90°Angle (Right)

Compatible Brand : Xmultiple

Mounting Type: Through Hole

Shielding: Shielded, EMI Finger

Temperature: ﹣40 TO ﹢85

Product Length (mm): 15.70

Product Height (mm): 13.50

Product Width (mm): 16.40

Part Number:XRJM-S-01-8-8-4
XRJM-S-01-8-8-X-F2

XRJM-S-01-8-8-4 Tab-Up 1×1 Port 8P/8C Tab-Up Shielded RJ45 Ethernet Connectors

Categories	Connectors, Interconnects
Categories	Modular Connectors - Jacks
Application-LAN	ETHERNET(NoN POE)
Connector Type	RJ45
Number of Positions/Contacts	8p8c
Number of Ports	1×1
Applications Speed	RJ45 Without Magnetics
Mounting Type	Through Hole
Orientation	90° Angle (Right)
Termination	Solder
Height Above Board	13.40 mm
LED Color	With LED
Shielding	Shielded, EMI Finger
Features	Board Guide
Tab Direction	UP
Contact Material	Phosphor Bronze
Packaging	Tray
Operating Temperature	-40°C ~ 85°C
Contact Material Plating Thickness	Gold 6.00µin/15.00µin/30.00µin/50.00µin
Shield Material	Brass
Housing Material	Thermoplastic
RoHS Compliant	YES-RoHS-5 WIth Lead in Solder Exemption
