Short Lead Time for mini rj45 connector - HFJ11-2450ERL 100 Base-T RJ45 Connector Modular Jack With Transformer – Zhusun Detail:

HFJ11-2450ERL 100 Base-T RJ45 Connector Modular Jack With Transformer

4

Categories  Connectors, Interconnects
 Modular Connectors - Jacks With Magnetics
Application-LAN  ETHERNET(NoN POE)
Connector Type  RJ45
Number of Positions/Contacts  8p8c
Number of Ports  1×1
Applications Speed  100 Base-T, AutoMDIX
Mounting Type  Through Hole
Orientation  90° Angle (Right)
Termination  Solder
Height Above Board  0.537″ (13.65mm)
LED Color  Without LED
Shielding  Shielded, EMI Finger
Features  Board Guide
Tab Direction  Down
Contact Material  Phosphor Bronze
Packaging  Tray
Operating Temperature  -40°C ~ 85°C
Contact Material Plating Thickness  Gold 6.00µin/15.00µin/30.00µin/50.00µin
Shield Material  Brass
Housing Material  Thermoplastic
RoHS Compliant  YES-RoHS-5 WIth Lead in Solder Exemption
