Trending Products RJ45 Connector Price - JFM24013-0L04-4F Single Port Tab Down 8P8C 100 Base-T RJ45 Connector With Transformer – Zhusun Detail:

JFM24013-0L04-4F Single Port Tab Down 8P8C 100 Base-T RJ45 Connector With Transformer

Categories	Connectors, Interconnects
Categories	Modular Connectors - Jacks With Magnetics
Application-LAN	ETHERNET(NoN POE)
Connector Type	RJ45
Number of Positions/Contacts	8p8c
Number of Ports	1×1
Applications Speed	10/100 Base-T, AutoMDIX
Mounting Type	Through Hole
Orientation	90° Angle (Right)
Termination	Solder
Height Above Board	0.537″ (13.65mm)
LED Color	With LED
Shielding	Shielded
Features	Board Guide
Tab Direction	Down
Contact Material	Phosphor Bronze
Packaging	Tray
Operating Temperature	-40°C ~ 85°C
Contact Material Plating Thickness	Gold 6.00µin/15.00µin/30.00µin/50.00µin
Shield Material	Brass
Housing Material	Thermoplastic
RoHS Compliant	YES-RoHS-5 WIth Lead in Solder Exemption

Product detail pictures:
