XFMRS XF-LCZ3A1CB Compatible ZhuSun Jack 10/100 Base-T Low Profile Ethernet Magnetics Transformer Single Port SMD
XFMRS XF-LCZ3A1CB Compatible ZhuSun Jack 10/100 Base-T Low Profile Ethernet Magnetics Transformer Single Port SMD
| Categories | Transformers |
| Network Transforme | |
| Transformer Type | ETHERNET(NoN POE) |
| PIN Contacts | 16 |
| Number of Ports | Single Port |
| Mounting Type | Surface Mount |
| Turns Ratio - Primary:Secondary | 1CT:1CT |
| Packaging | SMD |
| Operating Temperature | -40°C ~ 85°C |
| Comment | SAME AS NL VERSION |
| Construction | OPEN FRAME |
| RoHS Compliant | YES-RoHS-5 WIth Lead in Solder Exemption |
The RJ11 interface is very similar to the RJ interface, but only has 4 pins (8 for RJ). In computer systems, RJ11 is mainly used to connect modem modems. RJ11 usually refers to a 6-position (6-pin) modular jack or plug. This kind of connector has no international standard and is mentioned in the general integrated wiring standard. Moreover, this name is often used for 4-pin versions of modular connectors, causing confusion.
